Probabilistic forecasting of hourly Emergency Departement arrivals

.sticker-left[![isf](resources/stickeriff.jpeg)]
.sticker-float[![logo](resources/carbs_logo1.jpg)]

.center[.title[Probabilistic forecasting of hourly Emergency Department arrivals]]

.bottom[
Bahman Rostami-Tabar (<svg aria-hidden="true" role="img" viewBox="0 0 512 512" style="height:1em;width:1em;vertical-align:-0.125em;margin-left:auto;margin-right:auto;font-size:inherit;fill:#1da1f2;overflow:visible;position:relative;"><path d="M459.37 151.716c.325 4.548.325 9.097.325 13.645 0 138.72-105.583 298.558-298.558 298.558-59.452 0-114.68-17.219-161.137-47.106 8.447.974 16.568 1.299 25.34 1.299 49.055 0 94.213-16.568 130.274-44.832-46.132-.975-84.792-31.188-98.112-72.772 6.498.974 12.995 1.624 19.818 1.624 9.421 0 18.843-1.3 27.614-3.573-48.081-9.747-84.143-51.98-84.143-102.985v-1.299c13.969 7.797 30.214 12.67 47.431 13.319-28.264-18.843-46.781-51.005-46.781-87.391 0-19.492 5.197-37.36 14.294-52.954 51.655 63.675 129.3 105.258 216.365 109.807-1.624-7.797-2.599-15.918-2.599-24.04 0-57.828 46.782-104.934 104.934-104.934 30.213 0 57.502 12.67 76.67 33.137 23.715-4.548 46.456-13.32 66.599-25.34-7.798 24.366-24.366 44.833-46.132 57.827 21.117-2.273 41.584-8.122 60.426-16.243-14.292 20.791-32.161 39.308-52.628 54.253z"/></svg>[@Bahman_R_T](https://twitter.com/Bahman_R_T)) <br>With [Jethro Browell ](http://www.jethrobrowell.com/about-me.html) & [Ivan Svetunkov](https://www.lancaster.ac.uk/lums/people/ivan-svetunkov)
<svg aria-hidden="true" role="img" viewBox="0 0 496 512" style="height:1em;width:0.97em;vertical-align:-0.125em;margin-left:auto;margin-right:auto;font-size:inherit;fill:currentColor;overflow:visible;position:relative;"><path d="M131.5 217.5L55.1 100.1c47.6-59.2 119-91.8 192-92.1 42.3-.3 85.5 10.5 124.8 33.2 43.4 25.2 76.4 61.4 97.4 103L264 133.4c-58.1-3.4-113.4 29.3-132.5 84.1zm32.9 38.5c0 46.2 37.4 83.6 83.6 83.6s83.6-37.4 83.6-83.6-37.4-83.6-83.6-83.6-83.6 37.3-83.6 83.6zm314.9-89.2L339.6 174c37.9 44.3 38.5 108.2 6.6 157.2L234.1 503.6c46.5 2.5 94.4-7.7 137.8-32.9 107.4-62 150.9-192 107.4-303.9zM133.7 303.6L40.4 120.1C14.9 159.1 0 205.9 0 256c0 124 90.8 226.7 209.5 244.9l63.7-124.8c-57.6 10.8-113.2-20.8-139.5-72.5z"/></svg>[www.bahmanrt.com](https://www.bahmanrt.com/)
]

---
background-image: url("resources/hierarchy-left.jpeg")
background-size: contain
background-position: left
class: middle

.pull-right2[
## Outline

- Forecasting in Emergency Departments

- Data and forecasting setup

- Forecasting model development

- Forecast evaluation

- Conclusion & future works
]

---
background-image: url("resources/hierarchy-left.jpeg")
background-size: contain
background-position: left
class: middle

.pull-right2[
## Outline

- .remember[Forecasting in Emergency Departments]

- .gray[Data and forecasting setup]

- .gray[Forecasting model development]

- .gray[Forecast evaluation]

- .gray[Conclusion & future works]

]

---
.pull-left[
<img src="figure/isf_ed/ae_challenge1.png" width="600px">
<img src="figure/isf_ed/ae_challenge2.png" width="600px">
<img src="figure/isf_ed/ae_challenge3.png" width="600px">
]

.pull-right[
<img src="figure/isf_ed/ae_challenge4.png" width="500px">
<img src="figure/isf_ed/ae_challenge5.png" width="500px">
]

---
background-image: url("resources/as-staff.jpg")
background-size: 50%
background-position: right

.pull-left[
## Staffing problem
.large[How many nurses/doctors and When?]

- Demand/capacity planning
- Staffing
- Scheduling
]

.pull-right[
## Accurate staffing
- Reduces congestion in the service
- Improves the quality of provision for patients
- Reduce costs for the health system
- ...
]

---
## Forecasting meets staffing

---
.tiny[
<div id="htmlwidget-c02b64e3480ce9d2285b" style="width:100%;height:auto;" class="datatables html-widget"></div>
<script type="application/json" data-for="htmlwidget-c02b64e3480ce9d2285b">{"x":{"filter":"none","vertical":false,"fillContainer":false,"data":[["1","2","3","4","5","6","7","8","9","10","11","12"],["Cheng et al.","Choudhury and Urena","Asheim et al.","Hertzum","Kim et al.","Cote et al.","Chase et al.","Schweigler et al.","Jones et al.","McCarthy","Channouf et al.","Morzuch and Allen"],[2021,2020,2019,2017,2014,2013,2012,2009,2009,2008,2007,2006],["ED visits","ED arrivals","ED arrivals","ED arrivals","Hospital admission","ED arrivals","ED CUR","Bed occupancy","ED census","ED arrivals","Ambulance admission","ED arrivals"],["1h to 4 h\r\n","1h to 24h","3h","1,2,4,8,24 h","4h, 24h","24h","30m\r\n1h, 2h, 4h, 8h, 12h","4h, 12h","24h","n/a","1h, 3h, 6h, 12h, 13h, 14h, 17h, 23h, 24h\r\n","168h"],["1 year","4 years","5 years","3 years","3 years","2 years","1 year","4 years","2 years","1 year","2 years","3 years"],["SARIMAX, Holt-Winters, VAR, ARIMA","ARIMA; Holt-winters; TBATS; ANN","Poisson regression","linear regression; SARIMA; Naïve","Linear regression; Exponential smoothing; ARIMA; GARCH; VAR","Fourier regression","Binary regression","Hourly historical average; SARIMA; Sinusoidal model with autocorrelated error\r\n","VAR;  Holt winters","Poisson log-linear regression model","Regression","Double Exponential Smoothing; Additive Holt Winter"],["MSE, MAE, MAPE, Prediction interval coverage","RMSE, ME","MAPE","MAE, MAPE, \r\nMASE","MAPE","R^2,  Standard Error",null,"RMSE","MAE","Prediction interval coverage","\r\nRMSE","RMSE"],["NO","No","No","No","No","No","No","No","No","Yes","No","No"],["Single","Multiple","Single","Single","Single","Single","Single","Single","Single","Multiple","Single","Multiple"]],"container":"<table class=\"display\">\n  <thead>\n    <tr>\n      <th> <\/th>\n      <th>Author<\/th>\n      <th>Year<\/th>\n      <th>Variable<\/th>\n      <th>Horizon<\/th>\n      <th>Length<\/th>\n      <th>Method<\/th>\n      <th>Metric<\/th>\n      <th>Probabilistic<\/th>\n      <th>Seasonality<\/th>\n    <\/tr>\n  <\/thead>\n<\/table>","options":{"pageLength":12,"columnDefs":[{"className":"dt-right","targets":2},{"orderable":false,"targets":0}],"order":[],"autoWidth":false,"orderClasses":false,"lengthMenu":[10,12,25,50,100]}},"evals":[],"jsHooks":[]}</script>
]

---
## Literature limitations: relying on point forecast

.pull-left[
❌ Studies are limited to only predicting future arrivals as a point forecast (a single number)

- Point forecast is just an expected value and it creates the illusion of certainty

- An .remember[average is misleading and may be hiding somethings]
]

.pull-right[
<iframe width="600" height="550" src="https://www.youtube.com/embed/fZBW7rZB0I4?t=11" /iframe>

]

???

---
## Literature limitations

❌   most of studies do not consider the full extent of the multiple seasonality and changing profile over time

❌   Publications are not reproducible as underlying data and code are not available

❌   studies are limited in terms of the length of historical data used for training and forecast performance evaluation

❌   some studies in this area .remember[lack a rigorous experimental design], i.e. they do not use benchmark methods, report forecast accuracy or use cross-validation.

---
## Research Objetives

Based on this analysis and the literature review, we should consider developing probabilistic models that can take the following into account:

- Hour-of-day, day-of-week, and week-of-year seasonalities,
- Long-term trend (or a slowly changing level),
- Calendar events, such as holidays,
- Lags of calendar events to accommodate the potential changes in demand the next day after a
holiday,
- Other events, such as sporting fixtures,
- Temperature effects.

---
background-image: url("resources/hierarchy-left.jpeg")
background-size: contain
background-position: left
class: middle

.pull-right2[
## Outline

- .gray[Forecasting in Emergency Departments]

- .remember[Data and forecasting setup]

- .gray[Forecasting model development]

- .gray[Forecast evaluation]

- .gray[Conclusion & future works]
]

---

.pull-left[
<img src="figure/isf_ed/hourly-plot-ridge-1.png" height="600px">]

.pull-right[
- Daily seasonality
- Weekly seasonality
- Hourly attendance interacting with day of week
]

---
## Daily seasonality

.pull-left1[
<img src="figure/isf_ed/hourly-1.png" height="500px">
]

.pull-right1[
- Consistent pattern which repeats .remember[every 24 hours]
- Variation changes with mean
]

---
## Weekly seasonality

.pull-left1[
<img src="figure/isf_ed/seasonplot-dofw-1.png" height="500px">
]

.pull-right1[
- Consistent pattern which repeats .remember[every 7 days]
- but of course with lots of variation
]

---
## Week of year seasonality

.center[
<img src="figure/isf_ed/seasonplot-weekofyear-1.png" height="500px">
]
---

## Special events & holidays
### Effect of holidays and special events

.center[
<img src="figure/isf_ed/date-plot-1.png" height="500px">
]

---
## Forecasting setup

- Forecast horizon: 48 hours
- Time series cross validation with re-estimation
- One year of data for test

---
## Forecast accuracy metrics
### Point forecast

Evaluate the accuracy of point forecasts using Root Mean Squared Error (RMSE)

`\(RMSE = \sqrt{\frac{1}{h} \sum_{j=1}^h e_{t+j}^2}\)`

---
## Forecast accuracy metrics
### Probabilistic forecast

- Quantile Bias

- Shows the difference between the nominal exceedance of prediceted quantiles and the observed frequency of exceedance.

- Pinball score

.center[
<img src="figure/isf_ed/pinball.png" height="100px">
]

where `\(\mathcal{p} = \{0.05,0.1,...,0.95\}\)` is the set of quantiles being estimated.

---
background-image: url("resources/hierarchy-left.jpeg")
background-size: contain
background-position: left
class: middle

.pull-right2[
## Outline

- Staffing & Forecasting in Emergency Departments

- Data and experiment design

- Forecasting model development

- Forecast evaluation & findings

- Conclusion & future works
]

---
## Benchmark methods

- Poisson Regression

- ETS - Exponential Smoothing

- Prophet

- TBATS

- Gradient Boosting Machines

---
## ADAM: multiple seasonal iETSX

.center[
<iframe src="https://openforecast.org/adam/" width="100%" height="500px" data-external="1"></iframe>
]

---
## ADAM: multiple seasonal iETSX
.small[
.pull-left[
`\begin{equation}
	\begin{aligned}
	  & y_t = o_t z_t \\
		& \log z_t = \log l_{t-1} + \log s_{1,t-24} +\\
		&\log s_{2,t-168} + \\
	&	\mathbf{x}_t' \boldsymbol{\beta} + \log \left(1 + \epsilon_{t} \right) \\
		& \log l_{t} = \log l_{t-1} + \log( 1  + \alpha \epsilon_{t}) \\
		& \log s_{1,t} = \log s_{1,t-m} + \log( 1  + \gamma_1 \epsilon_{t}) \\
		& \log s_{2,t} = \log s_{2,t-m} + \log( 1  + \gamma_2 \epsilon_{t}) \\
		& o_t \sim \text{Bernoulli} \left(\mu_{a,t} \right) \\
		& a_t = l_{a,t-1} \left(1 + \epsilon_{a,t} \right) \\
		& l_{a,t} = l_{a,t-1}( 1  + \alpha_{a} \epsilon_{a,t}) \\
		& \mu_{a,t} = \min(l_{a,t-1}, 1)
	\end{aligned}
\end{equation}`
]
]

.pull-right[
.small[
- where `\(\alpha\)`, `\(\beta\)`, `\(\gamma_1\)`, `\(\gamma_2\)` and `\(\alpha_a\)` are the smoothing parameters, defining how adaptive the components of the model should be
- `\(l_t\)` is the level component for the demand sizes and `\(S_{t,1}\)` and `\(S_{t,2}\)` are the seasonal components
- `\(\beta\)` is the vector of parameters for the explanatory variables
- `\(o_t\)`  when demand occurs  is 1, otherwise 0
- `\(l_{a,t-1}\)` is the level component for the occurrence part of the model,
- scale of the distribution: `\((1 + \epsilon_t)\)` ∼ `\(Γ(s−1, s)\)`, where `\(s=\frac{1}{T} \sum_{t=1}^{T} e_{t}^2\)`
- `\(a_t\)` is an unobservable series, underlying the occurrence part of the model and `\((1 + \epsilon_{a,t})\)` is an unobservable error term for `\(a_t\)`.
]
]

---
## Generalised Additive Models for Location, Scale and Shape (GAMLSS)

- Assuming our forecast distribution follows a given parametric distribution.
- The forecast task would be to predict the future values of that distribution’s parameters.

- We then can use Generalised Additive Models for Location, Scale and Shape (GAMLSS).

- These are the distributional regression models where the parameters are modelled as additive functions of explanatory variables.

- This provides a powerful and flexible framework for probabilistic forecasting.

---
## Generalised Additive Models for Location, Scale and Shape (GAMLSS)

- `\(F_t(y_t)\)` is a predictive cumulative probability distribution of `\(y_t\)`
- `\(F_t(y_t)\)` is modelled via a parametric model, `\(F(y_t|\theta_t)\)`, where `\(\theta_t\)` is an `\(m\)`-dimensional vector of parameters
- In the GAMLSS framework [1] the elements `\(j=1,...,m\)` of `\(\theta_t\)` are modelled as

`\begin{equation}
    g_j(\theta_{j,t})=\mathbf{A}_{j,t} \beta_j + \sum_{i} f_{j,i}({x}^{S_{j,i}}_t), \;\;\; \text{for} \;\;\; j = 1, \dots, m,
\end{equation}`
`\begin{equation}
    f_{j,i}(x^{S_{j,i}}) = \sum_{k=1}^{K_{j,i}} b^{ji}_k (x^{S_{j,i}}) \beta_k^{ji},
\end{equation}`

.footnote[1 Rigby, R.A. and Stasinopoulos, D.M., 2005. Generalized additive models for location, scale and shape. Journal of the Royal Statistical Society: Series C (Applied Statistics), 54(3), pp.507-554.]

---
## GAMLSS

We start with a Poisson distribution with an additive model for `\(\log \lambda_t\)` of the form

`\begin{equation}
  \log(\lambda_t) = \sum_{i=1}^7 \beta_i \delta(D_i(t)-i) + \sum_{j=1}^7 D_j(t) f_j(H(t)) + t f_\text{Y}(Y(t)) + f_\text{Temp}(Y(t),C_t) \quad .
\end{equation}`

The functions `\(H(t)\)`, `\(D(t)\)` and `\(Y(t)\)` return the hour of the day (1-24), day of the week (1-7), and day of the year (1-366) at time `\(t\)`, respectively, and `\(C_t\)` is the temperature at time `\(t\)`. This model is called Poisson-1 in discussions below.

- we consider an extension to the additive models to incorporate school and public holidays into `\(D\)`. These models are labelled Poisson-2

---
More flexible, two-parameter distributions: the truncated Normal distribution, with truncation at 0.

`\begin{equation}
F_t(y_t,\mu_t,\sigma_t) =  \frac{\Phi\left( \frac{y_t-\mu_t}{\sigma_t} \right) - \Phi\left( \frac{-y_t}{\sigma_t} \right)}{1 - \Phi\left( \frac{-y_t}{\sigma_t} \right)}
(\#eq:truncatedn)
\end{equation}`

`\begin{align*}
	& \mu_t = \sum_{i=1}^{10} \beta_i D^{+}_i(t) + \sum_{j=1}^{10} D^{+}_j(t) f_j(H(t)) + t f_\text{Y}(Y(t)) + f_\text{Temp}(Y(t),C_t) \\
	& log(\sigma_t) = \sum_{i=1}^{10} D^{+}_i(t) f(H(t))
\end{align*}`

---
## A free course on GAM in R

.center[
<iframe src="https://noamross.github.io/gams-in-r-course/" width="100%" height="500px" data-external="1"></iframe>
]

---
## Detailed introduction to *GAM/GAMLSS*

.center[
<iframe src="https://www.taylorfrancis.com/books/mono/10.1201/9781315370279/generalized-additive-models-simon-wood" width="100%" height="500px" data-external="1"></iframe>
]

---
background-image: url("resources/hierarchy-left.jpeg")
background-size: contain
background-position: left
class: middle

.pull-right2[
## Outline

- Staffing & Forecasting in Emergency Departments

- Data and experiment design

- Forecasting model development

- Forecast evaluation & findings

- Conclusion & future works
]

---
## Summary results

.xsmall[
<table>
 <thead>
  <tr>
   <th style="text-align:left;"> Method </th>
   <th style="text-align:right;"> Quantile Bias </th>
   <th style="text-align:right;"> Pinball </th>
   <th style="text-align:right;"> RMSE </th>
   <th style="text-align:right;"> Time </th>
   <th style="text-align:right;"> Runnin Time </th>
  </tr>
 </thead>
<tbody>
  <tr>
   <td style="text-align:left;"> NOtr-1 </td>
   <td style="text-align:right;"> 0.010 </td>
   <td style="text-align:right;"> 1.223 </td>
   <td style="text-align:right;"> 0.268 </td>
   <td style="text-align:right;"> 451.6620471 </td>
   <td style="text-align:right;"> 451.662 </td>
  </tr>
  <tr>
   <td style="text-align:left;"> ADAM-iETSX </td>
   <td style="text-align:right;"> 0.010 </td>
   <td style="text-align:right;"> 1.417 </td>
   <td style="text-align:right;"> 0.090 </td>
   <td style="text-align:right;"> 92.9348605 </td>
   <td style="text-align:right;"> 92.935 </td>
  </tr>
  <tr>
   <td style="text-align:left;"> NOtr-2 </td>
   <td style="text-align:right;"> 0.012 </td>
   <td style="text-align:right;"> 1.209 </td>
   <td style="text-align:right;"> 0.268 </td>
   <td style="text-align:right;"> 86.5895462 </td>
   <td style="text-align:right;"> 86.590 </td>
  </tr>
  <tr>
   <td style="text-align:left;"> Ttr-2 </td>
   <td style="text-align:right;"> 0.014 </td>
   <td style="text-align:right;"> 1.210 </td>
   <td style="text-align:right;"> 0.332 </td>
   <td style="text-align:right;"> 956.5532849 </td>
   <td style="text-align:right;"> 956.553 </td>
  </tr>
  <tr>
   <td style="text-align:left;"> Prophet </td>
   <td style="text-align:right;"> 0.019 </td>
   <td style="text-align:right;"> 1.447 </td>
   <td style="text-align:right;"> 0.296 </td>
   <td style="text-align:right;"> 20.6755021 </td>
   <td style="text-align:right;"> 20.676 </td>
  </tr>
  <tr>
   <td style="text-align:left;"> ETS </td>
   <td style="text-align:right;"> 0.019 </td>
   <td style="text-align:right;"> 1.435 </td>
   <td style="text-align:right;"> 0.012 </td>
   <td style="text-align:right;"> 10.7175205 </td>
   <td style="text-align:right;"> 10.718 </td>
  </tr>
  <tr>
   <td style="text-align:left;"> Poisson-1 </td>
   <td style="text-align:right;"> 0.037 </td>
   <td style="text-align:right;"> 1.205 </td>
   <td style="text-align:right;"> 0.010 </td>
   <td style="text-align:right;"> 1.4763353 </td>
   <td style="text-align:right;"> 1.476 </td>
  </tr>
  <tr>
   <td style="text-align:left;"> Poisson-2 </td>
   <td style="text-align:right;"> 0.037 </td>
   <td style="text-align:right;"> 1.188 </td>
   <td style="text-align:right;"> 0.008 </td>
   <td style="text-align:right;"> 5.0768588 </td>
   <td style="text-align:right;"> 5.077 </td>
  </tr>
  <tr>
   <td style="text-align:left;"> NBI-2 </td>
   <td style="text-align:right;"> 0.054 </td>
   <td style="text-align:right;"> 1.206 </td>
   <td style="text-align:right;"> 0.383 </td>
   <td style="text-align:right;"> NA </td>
   <td style="text-align:right;"> NA </td>
  </tr>
  <tr>
   <td style="text-align:left;"> Benchmark-2 </td>
   <td style="text-align:right;"> 0.056 </td>
   <td style="text-align:right;"> 1.217 </td>
   <td style="text-align:right;"> 0.259 </td>
   <td style="text-align:right;"> 0.0947247 </td>
   <td style="text-align:right;"> 0.095 </td>
  </tr>
  <tr>
   <td style="text-align:left;"> GBM-2 </td>
   <td style="text-align:right;"> 0.060 </td>
   <td style="text-align:right;"> 1.262 </td>
   <td style="text-align:right;"> 1.777 </td>
   <td style="text-align:right;"> 602.4317496 </td>
   <td style="text-align:right;"> 602.432 </td>
  </tr>
  <tr>
   <td style="text-align:left;"> TBATS </td>
   <td style="text-align:right;"> 0.086 </td>
   <td style="text-align:right;"> 1.536 </td>
   <td style="text-align:right;"> 0.486 </td>
   <td style="text-align:right;"> 273.0558176 </td>
   <td style="text-align:right;"> 273.056 </td>
  </tr>
  <tr>
   <td style="text-align:left;"> Regression-Poisson </td>
   <td style="text-align:right;"> 0.093 </td>
   <td style="text-align:right;"> 1.294 </td>
   <td style="text-align:right;"> 0.849 </td>
   <td style="text-align:right;"> 67.1401641 </td>
   <td style="text-align:right;"> 67.140 </td>
  </tr>
  <tr>
   <td style="text-align:left;"> Benchmark-1 </td>
   <td style="text-align:right;"> 0.105 </td>
   <td style="text-align:right;"> 1.254 </td>
   <td style="text-align:right;"> 1.004 </td>
   <td style="text-align:right;"> 0.3874450 </td>
   <td style="text-align:right;"> 0.387 </td>
  </tr>
</tbody>
</table>
]
---
## Pinball

.pull-left1[
<img src="figure/isf_ed/results/pinball-1.png" height="500px">
]

.pull-right1[
- Consistent pattern which repeats .remember[every 24 hours]
- Weekly seasonality
- Hourly attendance interacting with day of week
]

---
## Quantile Bias

.pull-left1[
<img src="figure/isf_ed/results/quantile-bias-1.png" height="500px">
]

.pull-right1[
- Consistent pattern which repeats .remember[every 24 hours]
- Weekly seasonality
- Hourly attendance interacting with day of week
]

---
## Root Mean Squared Error

.pull-left1[
<img src="figure/isf_ed/results/lead-time-rmse-1.png" height="500px">
]

.pull-right1[
- Consistent pattern which repeats .remember[every 24 hours]
- Weekly seasonality
- Hourly attendance interacting with day of week
]

---
## Accuracy vs. running time

.center[
<img src="figure/isf_ed/results/time-accuracy-1.png" height="500px">
]

---
background-image: url("resources/hierarchy-left.jpeg")
background-size: contain
background-position: left
class: middle

.pull-right2[
## Outline

- Staffing & Forecasting in Emergency Departments

- Data and experiment design

- Forecasting model development

- Forecast evaluation & findings

- Conclusion & future works
]

---
## Conclusions

- Two approaches produced highly accurate, calibrated probabilistic forecasts:
      1. The first is ADAM-iESTX
      2. Labeled NOtr-2
- The point prediction produced by ADAM-iESTX had a lower RMSE than NOtr-2, while NOtr-2 produced forecasts with a lower pinball score.

- The .remember[choice of distribution assumed] for probabilistic forecasts and choice of .remember[model features] are as if not more important than the type of model employed;

- The best performing models .remember[handled the non-negative and skewed nature] of the data automatically without the need for post-processing.

---
## Conclusions

- Methods based on continuous-valued distributions are not adversely affected by the fact that the data are integer-valued. .remember[Rounding up predictive quantiles] to the next integer does not make predictions worse

- Out-of-the-box models, which require minimal tuning or manual development, do not perform as well as well-considered statistical approaches

- Of the models requiring a modest amount of user input and expertise, exponential smoothing (ETS) was found to perform well. However, its probabilistic forecasts were considerably worse than  NOtr-2 in terms of pinball score

- These observations reflect the characteristics of the data, which is representative of ED arrivals

---
## Future works

- More research is needed in the forecasting of other important variables such as .remember[length of stay, bed occupancy and waiting time], in addition to patient arrivals and admissions. This may require considering the dynamics among various services, including General Practitioners, Emergency Departments, Ambulance and Fire & Rescue services.

- .remember[Linking probabilistic forecasts] with .remember[upstream (ambulance call-outs) and downstream (medical outcomes)]

---
.pull-left[
Bahman Rostami-Tabar <br>
Associate Professor in Business Analytics
Cardiff University, UK
<br><br>

Slides @ [www.bahmanrt.com](www.bahmanrt.com)
<svg aria-hidden="true" role="img" viewBox="0 0 512 512" style="height:1em;width:1em;vertical-align:-0.125em;margin-left:auto;margin-right:auto;font-size:inherit;fill:#1da1f2;overflow:visible;position:relative;"><path d="M459.37 151.716c.325 4.548.325 9.097.325 13.645 0 138.72-105.583 298.558-298.558 298.558-59.452 0-114.68-17.219-161.137-47.106 8.447.974 16.568 1.299 25.34 1.299 49.055 0 94.213-16.568 130.274-44.832-46.132-.975-84.792-31.188-98.112-72.772 6.498.974 12.995 1.624 19.818 1.624 9.421 0 18.843-1.3 27.614-3.573-48.081-9.747-84.143-51.98-84.143-102.985v-1.299c13.969 7.797 30.214 12.67 47.431 13.319-28.264-18.843-46.781-51.005-46.781-87.391 0-19.492 5.197-37.36 14.294-52.954 51.655 63.675 129.3 105.258 216.365 109.807-1.624-7.797-2.599-15.918-2.599-24.04 0-57.828 46.782-104.934 104.934-104.934 30.213 0 57.502 12.67 76.67 33.137 23.715-4.548 46.456-13.32 66.599-25.34-7.798 24.366-24.366 44.833-46.132 57.827 21.117-2.273 41.584-8.122 60.426-16.243-14.292 20.791-32.161 39.308-52.628 54.253z"/></svg>[@Bahman_R_T](https://twitter.com/Bahman_R_T)
<svg aria-hidden="true" role="img" viewBox="0 0 448 512" style="height:1em;width:0.88em;vertical-align:-0.125em;margin-left:auto;margin-right:auto;font-size:inherit;fill:blue;overflow:visible;position:relative;"><path d="M100.28 448H7.4V148.9h92.88zM53.79 108.1C24.09 108.1 0 83.5 0 53.8a53.79 53.79 0 0 1 107.58 0c0 29.7-24.1 54.3-53.79 54.3zM447.9 448h-92.68V302.4c0-34.7-.7-79.2-48.29-79.2-48.29 0-55.69 37.7-55.69 76.7V448h-92.78V148.9h89.08v40.8h1.3c12.4-23.5 42.69-48.3 87.88-48.3 94 0 111.28 61.9 111.28 142.3V448z"/></svg> Connect: [Bahman ROSTAMI-TABAR](https://www.linkedin.com/in/bahman-rostami-tabar-1046171a/)
]

.pull-right[
## Outline

- Vaccine supply chain, challenges & the forecasting task

- Analysis of previous vaccine consumption & forecasting setup

- Hierarchical forecasting approaches

- Forecast accuracy improvement against the benchmark from the industry

- Conclusion & next steps
]
